Automatic Rotate Steel Ring Induction Heating Equipment For Hot Stamp

Delivery Time : 60 days

Keyword : induction heating machine

Place of Origin : Sichuan, China

key selling points : Patented Product

Certification : CE ISO

warranty : 12months

Price : $20,000

Feature : Fast heating and less oxide layer

Brand Name : DUOLIN

power(w) : 100-1500KW

MOQ : 1

Advantage : IGBT technology Energy saving

Contact Now

Automatic Rotate Steel Ring Induction Heating Equipment For Hot Stamp

Induction Heating Oven

Forging Support

Automatic Rotate Steel Ring Induction Heating Equipment For Hot Stamp

Induction forging refers to using an induction heater to pre-heat metals before forging. Typically, metals are heated to between 1,100 and 1,200 °C to increase their malleability and aid flow in the forging die. Induction produces less oxidation, is easy to control heating temperature and time, heats rapidly, ensures good quality of forging work pieces, and protects tools of forging machines.

Key Features

No combustible gases required
Rapid heating reduces oxide skin on billets
Improved working environment
Uniform heating temperature increases die life
Continuous operation capability - 24 hours non-stop
100% startup capability at any load
Minimal interference to other equipment in workshop (CE certified)
IGBT inversion technology & LC series circuit design achieve energy savings of 15%-30% compared with SCR technology
Easy to operate and maintain

Technical Parameters

Model	100D2	160D2	250D2	350D2
Rated Output Power	100 KW	160 KW	250 KW	350 KW
Power Capacity	140 KVA	230 KVA	340 KVA	450 KVA
Input Current	150 A	240 A	375 A	525 A
Frequency Range	0.5-10 KHz	0.5-10 KHz	0.5-10 KHz	0.5-8 KHz
Input Power	380V/50Hz 3 phases 4 lines (1 neutral line)
Duty Cycle	24 hours non-stop
Dimension	840×870×1840(mm)	1240×970×1940(mm)	1240×970×1940(mm)	1240×970×1940(mm)

steel ring induction heating equipment
